Water Jet Guided Laser
The precision laser CNC machine independently developed and designed by OPMT.
Enables high-precision machining of almost any material.
X/Y/Z Axis Travel
Customizable
Positioning Accuracy
5 μm（X/Y/Z Axis）
Repeat Positioning Accuracy
3 μm（X/Y/Z Axis）
Laser Source
Nanosecond
Coaxial observation system
Customized
Features
Reduced Thermal Damage
Rapid cooling minimizes the heat-affected zone, recast layers and micro-cracks.
Enhanced Quality
Efficient slag removal and surface cleaning improve surface quality and accuracy.
Flexible Machining
Independent of laser focus, it can extend working distances and enable taperless machining.
High Efficiency
Outperforms ultrafast laser machining with higher efficiency.
Wide Applicability
Suitable for machining metals, ceramics, composites, etc.
Environmentally Friendly
Uses only tap water.
Samples
Applications
Semiconductor
Medical Equipment
Jewelry
3C Electronics
Others
Specifications
Machine tool body
X/Y/Z Axis Positioning Accuracy(μm)
5
X/Y/Z Axis Repeat Positioning Accuracy(μm)
3
Rotary Axis Positioning Accuracy(“)
5
Rotary Axis Repeat Positioning Accuracy(“)
3
X/Y/Z Axis Travel
Customizable
Rotary Axis Travel
±120°/nx360°
Table diameter (mm)
125
Laser Source
Wavelength (nm)
532
Power(W)
100
Pulse width(ns)
150-300
Coupled system
Nozzle diameter(ym)
50-100
Processing line width (ym)
60-110
Coaxial observation system
Customized
Used for focusing and coupling debugging
High pressure water treatment system
Water pressure(MPa)
5-50
Accessories
Nozzle(100μm)
10
Filter Elements
2
